Drilling and Tapping

Sample drilling program

G81 X...Y...Z...R...F...K...
X - Hole coordinate on the X axis
Y - Hole coordinate on the Y axis
Z - Hole depth
R - Rapid retract point
F - Feed rate
K - Repeat count

00070
N0005 G54
N0010 T0505 G94:
N0015 S1500 M03 M08:
N0020 G90 X0 Y0:
N0025 G00 G43 Z50 H03:
N0030 Z5:
N0035 G81 X50 Y50 Z-30 R6 F100:
N0040 X100:
N0045 X150:
N0050 X200
N0055 Y100:

N0060 X150:
N0065 X100:
N0070 X50:
N0075 Y150:
N0080 X100:
N0085 X150:
N0090 X200:
n0095 G80:
N0100 G00 Z100:
N0105 X0 Y0:
N0110 M05 M09
N0115 M30:

Sample program with dwell at the bottom of the hole

G82 X...Y... Z...R... P... F... K...
X - Hole coordinate on the X axis
Y - Hole coordinate on the Y axis
Z - Hole depth
R - Rapid retract point
P - Dwell time at the bottom of the hole (milliseconds)
F - Feed rate
K — Repeat count

CNC milling programming - dwell at bottom of hole

00080
N0005 G54:
N0010 T0505 G94
N0015 S1500 M03 M08:
N0020 G90X0 Y0:
N0025 G00 G43 Z50 H03:
N0030 Z5:
N0035 G82 X50 Y50 Z30 R5 P1000 F100:
N0040 X100:
N0045 X150:
N0050 X200:
N0055 Y100:

N0060 X100:
N0065 Y150:
N0070 X100:
N0075 X150:
N0080 X200:
N0085 G80:
N0090 G00Z100:
N0095 X0 Y0:
N0100 M05 M09:
N0105 M30:

Sample program for peck drilling on a CNC mill

Explanation of the letters in the CNC milling program example: G83X... Y... Z... R... Q...F... K...
X - Hole coordinate on the X axis
Y - Hole coordinate on the Y axis
Z - Hole depth
R - Rapid retract point
Q - Peck amount
F - Feed rate
K - Repeat count

00090:
N0005 G54:
N0010 T0505 G94:
N0015 S1500 M03 M08:
N0020 G90X0 Y0:
N0025 G00 G43 Z50 H03:
N0030 Z5: N0090 X200
N0035 G81 X50 Z-30 R5 Q5 F100:
N0040 X100:
N0040 X150:
N0050 X200:
N0055 Y100

N0060 X150:
N0065 X100:
N0070 X50:
N0075 Yİ 50
N0080 X100:
N0085 X150:
N0090 G80:
N0100 G00Z100:
N0105 X0 Y0:
N0110 M05 M09:
N0115 M30:

Sample program for tapping on a CNC mill

Explanation of the letters in the CNC milling tapping program example: G84 X...Y...Z...R...P...F...K
X: Hole coordinate on the X axis
Y: Hole coordinate on the Y axis
Z: Thread length
R: Rapid retract point
P: Dwell time at the end of the thread
F: Thread pitch
K: Repeat count

00090
N0005 G54:
N0010 T0808 G94:
N0015 S200 M03 M08:
N0020 G90 X0 Y0:
N0025 G00 G43 Z50 H03:
N0030 Z5:
N0035 G84 X50 Y50 Z-30 R5 P100 F1:
N0040 X100:
N0045 X150:
N0050 X200:
N0055 Y100:

N0060 X150:
N0065 X100:
N0070 X50:
N0075 Y150:
N0080 X100:
N0085 X150:
N0090 X200:
N0095 G80:
N0100 G00 Z100:
N0105 X0 Y0:
N0110 M05 M09:
N0115 M30:

Sample program for drilling equally spaced holes on a bolt circle

00110:
M0005 G54:
M0010 T0101 G94:
N0015 S1800 M03 M08:
N0020 G90X0 Y0:
N0025 G00G43 Z50 H01:
N0030 Z5:
N0035 G81 X50 Y75 Z30 R5 F150:
N0040 G34X125 Y100 N10:
N0045 G00Z50:
N0050 G80:
N0055 G00X0 Y0:
N0060 G80:
N0065 M05 M09:
N0070 M30:

Explanation of the letters in the CNC milling bolt-circle drilling program example:
I – Distance of the circle center from the origin on the X axis
J – Distance of the circle center from the origin on the Y axis
N – Number of holes

CNC milling programming example – drilling on a bolt circle

Sample program to drill the Ø24 holes on the part shown below to a depth of 16mm

O1453 (ORNEK11)
N010 G91 G28 X0 Y0 Z0
N020 M06 T01
N030 M03 S1000
N040 G90 G54 G43 H1
N050 G52  X100 Y100
N060 G00 X0 Y0
N070 G00 Z5
N080 G16

CNC milling programming examples, hole milling

N090 G81 X80 Y45 Z-16 R2 F200
N100 Y135
N110 Y225
N120 Y315
N130 G15
N140 G52 X300 Y100
N150 G00 X0 Y0

N160 G16
N170 G81 X80 Y45 Z-16 R2
N180 Y135
N190 Y225
N200 Y315
N210 G15
N220 G28 Z0
N230 M30

Sample drilling program on a CNC mill 2

In the part shown below, the hole in the middle will be drilled with a 12mm bit, and the holes at the edges with a 6mm bit. Hole depth is 15 mm. Write the CNC program accordingly.

O1234 (ÖRNEK1);
N00 G90 G54 G40 G80 G21
N010 M6 T1 (12 DRILL)
N020 M03 S1000
N030 G00 X0 Y0
N040 Z5 G43 H1
N050 G01 Z-15 F400
N060 G28 Z0
N070 M6 T2 (6 DRILL)
N080 M03 S1600
N090 G00 X-22 Y -17
N100 Z5 G43 H2
N110 G01 Z-15 F400
N120 G00 Z5
N130 Y17
N140 G01 Z-15
N150 G00 Z5
N160 X22
N170 G01 Z-15
N180 G00 Z5
N190 Y-17
N200 G01 Z-15
N210 G28 Z0
N220 M05
N230 M30

CNC Milling Sample Applications – Pocket Milling

Rectangular pocket milling sample program

CNC milling sample programs, pocket milling

X - X-axis coordinate of the pocket's bottom-left corner
Y - Y-axis coordinate of the pocket's bottom-left corner
L - Pocket length along the X axis (Length)
W - Pocket length along the Y axis (Width)
Z - Pocket depth
R - Rapid approach distance
D - Side-shift amount for the cutter on the next pass
Q - Plunge depth per pass along the Z axis (Depth)
F - Cutting tool feed rate (Feed)

G24 X... Y... L... W... Z... R... Q... D... F...
T0303 - 12 mm end mill
00050;
N0005 G54
N0010T0303 G94:
N0015 S1500 M03 M08;
N0020 G90 X0 Y0;
N0025 G00 G43 Z50 H03:
N0030 Z5;
N0035 G 24 X20 Y20 L80 W162 Z 10 R3 Q6 D3 F125;
N0040 G24 X120 Y20 L110 W50 Z-10 R3 Q5 D3 F125:
N0045 G24 X120 Y90 L110 W92 Z-10 R3 Q6 D3 F125;
N0050 G00Z100;
N0055 XO Y0; N0060 M05 M09; N0065 M30:

Circular pocket milling sample program

O0060
N 0005 G54
N0010 T0202 G94
N0015 S1500 M03 M08
N0020 G90 X0 Y0
N0025 G00 G43 Z50 H03:
N0030 Z5:
N0035 G25 X35 Y100 I125 J100 Z-10 R3 Q5 D3 F150;
N0040 G00 X125 Y100
N0045 Z-5;
N0040 G25 X75 Y100 I125 J100 Z-20 R-8 Q5 D3 F150
N0050 G00 Z100
N0055 X0 YO;
N0060 M05 M09;
N0065 M30;

Explanation of the letters in the CNC milling circular pocket milling program example:
X – X-axis coordinate of a point on the circle
Y – Y-axis coordinate of a point on the circle
I – Distance of the circle center from the origin on the X axis
J – Distance of the circle center from the origin on the Y axis
Z – Pocket depth
R - Rapid approach distance
D - Side-shift amount for the cutter on the next pass
Q – Plunge depth per pass along the Z axis (Depth)
F – Cutting tool feed rate (Feed) T0202 — 10 mm end mill
